Edgebander STREAMER 1054 C: Impressive performance spectrum including jointing

STREAMER 1054 C Edgebander: Edgebanders for wood and panels in the compact class

The STREAMER 1054 C edgebander offers a new feature: A digital logbook for reliable and simple setup of your edgebander (VI.SE. - visual setting system).

The basic idea behind the entire STREAMER series is to achieve excellent results within a very small space. At 3.96 meters the STREAMER 1054 C edgebander is extremely compact and has a great assembly package for perfect edging with invisible joints. PUR processing is also possible as a standard feature.

As with the large models, the panels are prepared by a premilling cutter unit for the edgebanding process.

Prices
x

Different requirements - different prices

The price of a HOLZHER machine is just as individual as your requirements are. Therefore, let us discuss briefly what is most important to you – you will then receive our preliminary, non-binding quote.

  1. I hereby consent to allow my data, entered above, to be processed in Weinig Group systems pursuant to the data privacy statement for the purpose of answering and documenting my inquiry.
Personal advice
x

Personal advice – for higher productivity and greater efficiency

Together with your HOLZHER expert you will find the ideal machine for your requirements. Simply submit the completed form, and your local HOLZHER expert will be happy to discuss all further details with you.

  1. I hereby consent to allow my data, entered above, to be processed in Weinig Group systems pursuant to the data privacy statement for the purpose of answering and documenting my inquiry.

Here is what the HOLZ-HER STREAMER 1054 C offers

  • Workpiece thickness up to 60 mm
  • Edge Thickness up to 8 mm
  • 2 finishing units

Technical Details

Control unit Edge Control BC 15 with 15.6" touch screen

Control unit Edge Control BC 15
  • Colour screen 16:9
  • Powerful control system with simple graphic operation
  • Rotating and tilting control panel at eye level
  • Network-compatible
  • Operator access with password protection
  • Quick setting between PUR and EVA
  • VISE function

Vi.se. (VIsual SEtting mode)

VISE provides all setting values for the digital counters and pressure gauges as a digital logbook to set up the machine quickly and safely.

The display is interactive via the 15.6" touch control panel.

Jointing cutter unit - 45 (60) mm

Jointing cutter

Perfect preparation

Cut edgings often have small tears in the top layer. The jointing cutter unit ensures perfect glued surfaces and prepares the panels for the gluing process.

For perfect edge appearance and top quality, all HOLZ-HER edgebanders are equipped with diamond tipped cutters with integrated chip evacuation as well as high concentricity and long service life. The jointing cutters have patented purging holes to effectively prevent double machining, thus increasing the service life significantly. In addition a height adjustment feature is included for optimum utilization of the cutters.

  • Optionally available with working height of 60 mm.

Edging feed

Edging feed

Fully automatic, user-friendly feeder for coiled edging as well as single strip feeder. Gentle material handling with transport belts for edging transport and automatic edge recognition.

An edging separator is available (as an option) for practical processing of packages of edging strips.

Pressure unit

Pressure unit

High quality 3-roller pressure unit for pressing edging against panel cleanly and forcefully. First roller motor-driven, two subsequent pressure rollers.

Pneumatic, application-controlled pressure unit.

Glu Jet - The flexible glue application system

GluJet - The most flexible glue application system on the market

Heat-up, glue change and cleaning require only  3 minutes each

Hardly any other glue application system offers this flexibility with such energy efficiency and cleanliness. HOLZ-HER thin film technology makes this gluing system an all rounder for craftsmen and industrial users. Invisible joints with PUR glue, which can also be used in wet areas, are an obvious choice for HOLZ-HER customers.

Brilliant appearance, regardless of material - Starting with the state-of-the-art, high gloss edging right up to solid wood edging with extremely high cross sections. HOLZ-HER sets the trends for tomorrow today.

Trimming unit - 60 mm

Pneumatic trimming unit - 60 mm

For straight or chamfered trimming on thin edging; unit pivots manually to 10 degrees.

  • With 60 mm working height, pivots pneumatically.
    High quality version with stable cast stand and two sawing motors each on two guides.

Cutter unit

Pneumatic cutter unit

Multifunction cutter unit for flush cut on edging with thickness up to 8 mm, radiuses up to 3 mm.
Including quick adjustment flush / radius as well as diamond tipped tools.

Scraper unit for perfect finishing

Scraper unit, HOLZ-HER Streamer edgebander
  • For perfect smoothing of radiuses and chamfers on plastic edging.

Flat scrapers

Flat scrapers

With plunge control

  • The application-controlled flat scraper removes all glue residues, which are then blown off the panel by the integrated blast nozzles

With pre- and post-sensing (optional)

  • Clean surface finishing with pre- and post-sensing

Buffing unit

Buffing unit for polishing work during finishing - HOLZHER Streamer edgebanders
  • Polishing for maximum gloss; for complete finishing

Technical Details

Energy savings made easy

The intelligent ECO Mode energy management for HOLZ-HER edgebanders not only helps preserve our environment - it also saves you money.

Learn more


Are you still "rolling" glue or are you already saving?

Are You Already Saving?

Are you still "rolling" glue or are you already saving? Savings of up to € 1,000 / year with our patented Glu Jet nozzle system.

Learn more


References


Further information

Brochures

Simple, fast and sustainable: more details in a downloadable PDF document.

STREAMER C brochure (PDF, 3 MB)
